QSAN XN5004T - 4 Bay Hybrid NAS Storage
The QSAN XCubeNAS XN5004T is a simple, solid, and stylish NAS system that is designed for Workgroup and SMB applications. The XCubeNAS is powered by specified hardware N+1(3.5’’ LFF xN + 2.5’’ SFF x1) design, with an additional onboard SATA SSD slot for blazing performance and capacity expansion that can benefit every workgroup and SMB user.
QSAN XN5004T
Applications
Innovative (4+1) Hybrid Storage Capacity
The innovative mechanical design makes the XCubeNAS a versatile hybrid storage device. Without affecting existing large form factor slots, the XCubeNAS positions small form factor bays for SATA SSD at the left side of the system, this way we can ensure that both the demands for capacity and performance can be satisfied.
N: Large Form Factor Large form factor slots drive trays to feature not only 3.5-inch drive support but also 2.5-inch mounting holes are included as standard on all bays on the XCubeNAS. Fitted with up to 10TB drives in the 3.5 inch HDD bays, the XCubeNAS can fulfill capacity demands, and exceed them after adding our XCubeDAS systems.
1: Small Form Factor Additional 2.5-inch small form factors are provided in order to enable advanced features without sacrificing storage capacity. In addition to being used for SSD caching for boosting data access performance, our auto-tiering architecture can be utilized to offer a complete ongoing optimization.
Built off of QSM OS 3.0 and 3.1, all QSAN NAS units are run on the latest QSM OS 3.2
Advantages
Technical Specifications
SATA 3.5\": 1TB, 2TB, 3TB, 4TB, 6TB, 8TB, 10TB, 12TB, 14TB, 16TB, 18TB, 20TB, 22TB, 24TB, 26TB
SSD 2.5\": 960GB, 1.9TB, 3.8TB, 7.6TB, 15.4TB, 30.7TB
S.M.A.R.T., NCQ, and OOB Staggered Spin-up capable drives supported.
Intel® Celeron® 2.9GHz Dual-Core Processor
8GB DDR4 ECC U-DIMM, up to 32GB - *Note: The pre-install memory modules may need to be replaced when expanding the memory.
4 LFF with lock
1 SFF
No. of Internal Hard Disks: 5: (LFF disk ) + 1 (SFF disk)
Max. Raw Capacity: 42TB: 10TB x4 + 2TB x1 - (Note: LFF=10TB, SSF=2TB)
Hard Drive Interface: SATA 6Gb/s (backward compatible with SATA 3Gb/s)
USB 3.0 x5
HDMI: 1
Flash: 8GB USB DOM
Ethernet Ports: 1 GbE LAN (RJ45) x4
PCIe Gen3x8 for 10 GbE/ 40 GbE / Thunderbolt 3.0 / SAS adapter cards
NAS application server (Gigabit/10GbE/40GbE NIC)
iSCSI storage (Gigabit/10GbE/40GbE NIC)
Direct attached storage with Thunderbolt 3.0 (40GbE/s)
File Server
File sharing across Windows/Mac/Linux/UNIX and centralized management
FTP Server
Supports data access from a remote location via FTP
FTP with SSL/ TLS (explicit) mode
FXP supported
FTP bandwidth control and connection control
Passive FTP port range control
Backup Server
XReplicator
3rd party backup software support: Acronis True Image, CA Brightstor ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie Silverkeeper
Snapshot replica
Time machine backup server
External storage device backup
Block-level real-time remote replication supports instant, schedule backup management
XMirror (Multi-side data synchronization)
Cloud backup: Amazon S3
Cloud synchronization: Google Drive, Windows OneDrive, Dropbox
Web Server
Built-in phpMyAdmin
SQL Server
MariaDB database serve
VPN Server
Supports OpenVPN, PPTP, and IPsec+L2TP
Virtualization Server
Virtual machine import/export
Virtual machine backup
Virtual machine Snapshot
User-based permissions settings
Support virtual switch
Supports access from IE, Safari, Firefox, Chrome
Multiple OS: Windows, Linux, UNIX, and Android
VLAN
Link aggregation (support 7 bonding modes)
Multi-IP settings
Gigabit Jumbo Frame
File System
ZFS file system
EXT2 (Virtual Volume)
EXT3 (Virtual Volume)
EXT4 (Virtual Volume)
FAT (Virtual Volume)
NTFS (Virtual Volume)
Disk Management
Single disk, RAID 0 (Disk Striping), RAID 1 (Disk Mirroring), RAID 5, RAID 5 + hot spare, RAID 6, RAID 10, RAID 50, RAID 60, and JBOD (Linear Disk Volume)
Multiple volume and storage pool
User-defined storage (Generic, Media, Database)
Online pool/volume Capacity Expansion
Pool/ volume usage threshold notification
Self-encrypting drives (SED) pool level protection
Pool write cache
Scrub pool
Convert cloned volume
Virtual volume (mount disk from remote iSCSI target)
Set free and replace disk
HDD S.M.A.R.T.
Built-in iSCSI target and initiator service
External device management
Global and dedicate hot spare disk
Zero time RAID creation and quick rebuilding
Auto Tiering
SSD read/write cache
Deduplication
User Management
Local / domain user and group management
Local / domain application privilege
User quota for local and domain user
Home folder
Windows AD and LDAP
Trust domain and support up to 200,000 domain users
Folder Management
Advance file ACL
Windows AC
Hide shared folder on Windows network
Unicode support
WORM (Write Once Read Many protection)
Folder usage threshold notification
Folder quota
System Tool
NTP time settings
Notification: E-mail alert (SMTP authentication), syslog, and SNMP
System firmware upgrade
Back up, restore, reset system settings
Import system configuration
Antivirus
Smart fan
IP access control
Policy-based unauthorized IP blocking
Secure remote login by SSH connection
Connection list management
USB, SNMP UPS suppor
Network recycle bin
Import SSL certificate
Real-time Resource (CPU, Memory, Storage, Disk, Process) / Hardware/ service/ network resource monitor
Power Management
HDD hibernation
Power schedule
Wake on LAN
UPS settings
Recover from power outage
File Manager
File preview
Embedded file player
Filter
Mount Cloud (Google Drive, OneDrive, Dropbox)
ISO image mount
CIFS, FTP, SFTP, and WebDAV client
Share link
Team folder sharing
Publish to facebook, twitter, weibo
Media library
Media streaming
Online doc preview and editing
Transcoding (online/offline), compression
Multi Browser Support
Internet Explorer
Safari
Firefox
Google Chrome
Data service: CIFS, AFP, NFS, FTP, WebDAV
Backup service: Rsync
Discover service: Bonjour
Operating temperature: 0 to 40°C
Shipping temperature: -10 to 50°C
Operating relative humidity: 20% to 80% non-condensing
Non-operating relative humidity: 10% to 90%
FCC Class A • CE Class A • BSMI Class A • VCCI Class A • RCM Class A • KCC Class A
VMware 8, Windows Server 2022, Ubuntu 22.04 LTS, RHEL 9, CentOS 9, Debian 11
177 x 190 x 235 mm
QSAN XN5004T
Advanced Features
- Innovative hybrid hardware architecture
- Standard LFF (Large Form Factor) bays plus exclusive SFF (Small Form Factor) bays
- Brand new enterprise level QSM 3.1 with all new interface and enterprise features
- Unified storage architecture with full virtualization support
- Completed backup plan for unexpected hardware failure, natural disasters, or simple accidental deletion
- Optimized storage features: Auto Tiering, Thin Provision, Data deduplication, and SSD cache
- Security enhancement: Pool and disk encryption, WORM technology, Antivirus, VPN service, and IP connection filter
